    Power test cable connector with dual safety banana plugs to DC power socket, electrical wire harness for battery charger, inverter, solar system and

    Ask Lasest Price
    Brand Name : ShuangYi
    Model Number : Medical cable D-sub 7P Mx2 TO nextron Connector(RMA G0P4220140)
    Certification : ROHS, HF, ISO 9001, ISO 14001, IATF 16959
    Price : $1.44-2.21 PCS FOB
    Payment Terms : T/T
    Supply Ability : 500000 pcs per month
    Delivery Time : 8-15 working days
    • Product Details
    • Company Profile

    Power test cable connector with dual safety banana plugs to DC power socket, electrical wire harness for battery charger, inverter, solar system and

    Product Description

    This power cable assembly combines two insulated banana plug terminals with a robust DC power connector to provide a safe and reliable interface between test instruments and DC equipment. The stranded tinned copper wire ensures efficient electrical transmission with minimal power loss, while the flexible white jacket allows easy routing inside cabinets, racks and charging stations. An integrated ferrite core helps reduce electromagnetic interference on power and signal circuits, improving stability in sensitive electronic and PCB-based systems.

    The harness can be fully customized to match different connector series, pin layouts and current ratings. Options include alternative terminal types, wire gauges, jacket materials and printed identification, making it suitable for OEM battery chargers, automotive electronics and industrial power supplies that require tailored wiring solutions.


    Power test cable connector with dual safety banana plugs to DC power socket, electrical wire harness for battery charger, inverter, solar system andPower test cable connector with dual safety banana plugs to DC power socket, electrical wire harness for battery charger, inverter, solar system andPower test cable connector with dual safety banana plugs to DC power socket, electrical wire harness for battery charger, inverter, solar system and

    Product typePower test cable / DC power wire harness
    Connector 1Dual insulated safety banana plug terminals (red polarity)
    Connector 2DC power connector socket, gray housing, locking sleeve
    Conductor materialStranded tinned copper wire for low-loss power transmission
    Wire gauge16–18 AWG (other gauges customizable)
    Rated voltageUp to 600 V DC, depending on cable size and insulation
    Rated currentUp to 20 A continuous (higher current versions available)
    Outer jacketFlexible PVC or XLPE insulation, white cable jacket
    Cable lengthStandard 1.0–2.0 m; customized length and tolerance available
    Ferrite coreIntegrated ferrite sleeve for EMI/RFI suppression on power and signal lines
    Working temperature-20°C to +105°C typical
    Application areaAutomotive test benches, battery chargers, inverter racks, solar controllers, server power modules
    Custom optionsWire color, printing, connector type, labeling and terminal pitch can be customized

    Applications

    Connecting laboratory power supplies to battery packs, DC loads and electronic testers

    Power harness for inverter, solar controller and energy-storage systems in R&D environments

    Interface cable between automotive diagnostic equipment and vehicle DC power terminals

    Internal power link between server power modules and distribution boards in test racks

    Temporary connection for PCB prototypes, power converters and electronic evaluation boards

    Precautions

    Verify voltage, current and polarity before connecting to prevent damage to equipment.

    Ensure banana plug terminals and DC connector are fully inserted and locked to avoid overheating or arcing.

    Do not exceed the specified current rating; choose a larger wire gauge for higher power applications.

    Avoid sharp bends, abrasion and contact with hot surfaces; secure the cable with clips or cable ties where necessary.

    Disconnect the power source before plugging or unplugging the connector during maintenance or reconfiguration.
