    SATA 7-Pin Wire Solder Female Connector, 1.27mm Pitch PCB Signal Power Interface, Custom Electrical Terminals for HDD SSD Server Storage Transmission

    Product Description

    This SATA female wire-solder connector is designed for reliable signal and power transmission in compact electronic assemblies. The 7-pin layout with 1.27 mm pitch supports standard SATA interfaces, providing stable high-speed data links between drives and host boards.

    Contacts are made from copper alloy with nickel under-plating and selective gold on the mating area, ensuring low contact resistance and long-term corrosion resistance. Tin-plated solder tails make cable assembly easier and help maintain strong solder joints. The high-temperature, flame-retardant housing withstands reflow heat and harsh operating environments while maintaining mechanical strength.

    With flexible wire solder terminations, this connector is ideal for custom wiring harnesses, allowing manufacturers to choose cable length, wire gauge and pin assignments to match their own PCB layouts and system requirements.


    SATA 7-Pin Wire Solder Female Connector, 1.27mm Pitch PCB Signal Power Interface, Custom Electrical Terminals for HDD SSD Server Storage TransmissionSATA 7-Pin Wire Solder Female Connector, 1.27mm Pitch PCB Signal Power Interface, Custom Electrical Terminals for HDD SSD Server Storage TransmissionSATA 7-Pin Wire Solder Female Connector, 1.27mm Pitch PCB Signal Power Interface, Custom Electrical Terminals for HDD SSD Server Storage Transmission

    Connector typeSATA female wire-solder connector
    FunctionCombined power and high-speed signal transmission
    Pin count7 pins (custom pin count available on request)
    Pitch1.27 mm nominal
    Termination typeWire solder type, rear solder cup/flat tail
    Mounting styleCable-end connector, mates to SATA PCB receptacle
    Contact materialCopper alloy
    Contact platingNickel under-plating, selective gold on mating area, tin on solder tails
    Insulator materialHigh-temperature thermoplastic, UL94-V0
    Rated voltageUp to 5–12 V DC (depending on system design)
    Rated currentUp to 1.5 A per contact (application dependent)
    Wire size rangeTypically AWG 26–22 stranded cable
    Operating temperature–20 °C to +85 °C
    Insulation resistance≥ 1000 MΩ (typical)
    Dielectric withstand500 VAC 1 minute (typical lab condition)
    Contact resistance≤ 30 mΩ (initial)
    ColorBlack housing
    CustomizationCable length, wire gauge, pin assignment and plating options customizable
    ComplianceRoHS compliant, halogen-free options available

    Applications

    Internal SATA cable assemblies for HDD and SSD storage devices

    Wiring harnesses for server and data-center storage backplanes

    Embedded industrial PCs, DVR/NVR and telecom equipment requiring compact SATA links

    Customized automotive data loggers and onboard recorders needing high-reliability signal and power connectors

    Any PCB-to-cable application where a low-profile SATA female connector is required

    Precautions

    Ensure the pin assignment and SATA signal definition match the mating PCB connector before production.

    Do not exceed the recommended current and voltage ratings; derate appropriately in high-temperature environments.

    Use proper strain relief and cable clamping in the final assembly to avoid stress on solder joints.

    Keep contacts free from contamination and avoid repeated mating with damaged plugs to maintain low contact resistance.

    Store connectors in a dry, dust-free environment and avoid exposure to corrosive chemicals before assembly.
